Slurry-Residue Dryer

Capacity:  1000-5000 kg/ hour
Power: 32-165 kw
Application: suitable to drying slurry-residue
Hotline:+86-371-56739888
  • Processing customized:yes
  • Product brand:DINGLI
  • Specifications:DLJG2912/3
  • Daily Capacity:5000 kg/ h
  • Power:165kw
  • Weight:45500kg
  • Warranty: 1 year
  • Place of Origin: Henan, China (Mainland)
  • Plant Area :10m*20m

The sawdust dryer is used for pellet sawdust or powder sawdust. Wet materials are continuously sent into drum through screw conveyer and then get separated and pushed by high-speed hot flow. The moisture in wet materials is taken away in this process and then we get powder or pellet dry materials.


High performance price ratio

Automatic control, to ensure the drying of sawdust water even and stable.Automatic stone removing and iron removal can ensure that the impurities of the sawdust are not in the rear process.The required investment of equipment is 1/6 of imported products.



Energy conservation

Compared with the single cylinder drier, the utility model reduces the occupation cost by about 50%, reduces the civil investment by about 50%, A variety of material combinations Zhou Xiangyang distribution, effectively control the drying time.



Better quality

Cylinder self insulation, thermal efficiency of more than 70%, With tail drive, the transmission is more stable and reliable; completely change the wheel rotation, often slip shadow, Sound production phenomenon.



Widely used

Frequency control is adopted to control material flow, and the final water can be easily controlled according to the needs of users Sub index. The air outlet temperature is low, and the dedusting equipment can be used for a long time.



Device Specification

DLJG1208 DLJG1408 DLJG1610 DLJG2010/3 DLJG2210/3 DLJG2510/3 DLJG2512/3 DLJG2912/3

Daily Processing Capacity(t/d)

33.6 40.8 58.9 131.4 145.0 167.7 204.0 247.0

Daily Output(t/d)

15.6 19.2 27.7 61.8 68.2 78.9 96.0 116.2

Water Evaporation Capacity (t/h)

0.75 0.90 1.30 2.90 3.20 3.70 4.50 5.45

Raw Material Water Content(%)

60±5%

Dried Material Water Content((%)

12-15%(adjustable)

Drying Temperature

350-550℃

Total Installed Power (kw)

32 40 55 95 100 125 145 165

Total Weight(kg)

15000 17000 21500 26500 28500 370000 41000 45500

Plant Area(m2)

5m*14m 5m*14m 6m*16m 8m*16m 8m*16m 10m*16m 10m*18m 10m*20m
